The central granite

Unit: P 22 (affected by IG 2)

image TI-18

full-size image

Interbedded fine sandstones and siltstones thermally metamorphosed by the Central Granite. This is indicated by the cordierite spots in the finer grained horizons. (Cordierite is a mineral which develops as a result of contact metamorphism of Mg-Al rich argillaceous sediments).

Scale: coin is 20 mm in diameter

Grid reference: 936 269
